Autel IM608 PRO II vs. IM608 vs. IM508 vs. KM100

This is a Autel MaxiIM series comparison, covering Autel MaxiIM IM608 II, IM608, IM508 & KM100 key programmers. To find out the differences, we’ve compared from hardware configuration & software functions. Let’s take a look.

Autel MaxiIM Series Tools Comparison

Item Autel IM608 PRO II/ IM608 II/ IM608S II Autel IM608 PRO/ IM608 Autel IM508 Autel KM100
Hardware Touch screen tablet & programmer Touch screen tablet & programmer Touch screen tablet & programmer Touch screen handset
VCI connection √ (Bluetooth connection) √ (Bluetooth  connection) √ (wire connection) √ (Bluetooth connection)
Automatic scan
Immo scan
Immo function Support program keys by OBD/on-bench/boot, immo part replacement Support program keys by OBD/on-bench/boot, immo part replacement Support program keys by OBD/on-bench/boot, immo part replacement Support program keys by OBD
Diagnostic function Medium diagnosis, BMW & Benz immo programming Medium diagnosis, BMW & Benz immo programming Basic diagnosis ×
Remote expert √ (coming soon) × × ×
Processor Qualcomm SDM660 Octa-core Samsung Exynos T5260 6-Core Rockchip RK3188 Quad core PX30 4x ARM Cortex-A35
System Android 10.0 Android 4.4.2, KitKat Android 4.4.4 Android 9.0
RAM 4G 2G 1G 2G
ROM 128G 64G 32G(64G after 2021) 64G
Screen 10.1inches,  1920*1200 10.1inches,  1920*1200 7inches, 1024*600 5.5inches, 1280*700
WiFi
Bluetooth V5.0+BR/EDR V2.1+EDR ×
USB USB 2.0 (2 USB host type A, 1 USB mini device) USB 2.0 (2 USB host type A, 1 USB mini device) USB 2.0 (1 USB host type A, 1 USB mini device) ×
HDMI HDMI 2.0 HDMI 1.4A × ×
SD Card √ (support up to 64G) √ (support up to 32G) √ (support up to 32G) ×
Headphone jack × ×
Microphone 1MIC 1MIC × ×
Loudspeaker 2 2 × ×
GPS × × ×
Light sensation × ×
Buttons 1 power button 1 power button 1 power button ×
Battery 3.8V, 15000mAh 3.8V, 15000mAh 3.7V, 5000mAh 4950mAh
Camera Rear 16 megapixel, AF with flashlight Rear 8 megapixel, AF with flashlight × ×
VCI JVCI+ JVCI All-in-one V200
Programmer XP400 PRO XP400 PRO XP200 ×
Connection Bluetooth/USB Bluetooth/USB All-in-one Bluetooth
Read & write EEPROM ×
Read & write MCU √ (less coverage) ×
Read & write ECU √ (less coverage) ×
Read & write immo module √ (less coverage) ×
Read & write instrument/ airbag module √ (less coverage) ×
Key identify √ (less coverage)
Write by dump × ×
Refresh key √ (need XP400 PRO)
Detect frequency √ (need XP400 PRO)
Generate transponder √ (need XP200, XP201, XP400, XP401, XP400 PRO, XP401 PRO) √ (need XP200, XP201, XP400, XP401, XP400 PRO, XP401 PRO) √ (need XP200, XP201, XP400, XP401, XP400 PRO, XP401 PRO)
Transponder simulation √ (need APB112) √ (need APB112) √ (need APB112)
Detect ignition coil √ (need APB112) √ (need APB112) ×
Auto VIN ×
Read & clear fault codes ×
Live data ×
Freeze frame ×
Read ECU info ×
Action test ×
Services ×
Special function ×
Online coding × ×
Offline coding × ×
Hidden features × ×
Guidance × ×
Online programming √ (support partial Benz, BMW models) √ (IM608Pro supports partial Benz, BMW models) × ×
Report manage ×
Other functions Scan VIN, scan license, remote desk.

D-PDU, RP1210, DoIP, CANFD diagnostic standard

Remote desk, D-PDU, RP1210 diagnostic standard (DoIP/CANFD need adapter) Remote desk, CANFD diagnostic standard(need adapter) ×
Inspection camera √ (MV105/ MV108) √ (MV105/ MV108) √ (MV105/ MV108) ×
