    VAG CAN PRO V5.5.1 with FTDI FT245RL Chip VCP OBD2 Diagnostic Interface USB Cable Support Can Bus UDS K Line Works for A

    • Item No.  OB131
    • History: 52  sold
    • Quantity
      Express Shipping Service    Estimated delivery time: 5-7 days »
      Affected by the epidemic, there will be delays in transit time.
    • Quantity:  Out of stock
    • Weight:  100.0gram
    • Rank:  comment rank 5 () Write a Review
    • Member Benefits  Shipping  Return Policy




    Technical Support


    VAG CAN PRO V5.5.1 with FTDI FT245RL Chip VCP OBD2 Diagnostic Interface USB Cable Support Can Bus UDS K Line Works for AUDI/VW

    Systems required: Windows 7 / 8 and Windows XP , NOT WORK WITH WIN10

    VAG PRO support CAN BUS + UDS + K-Line for diagnostics and programming of electronic components used in vehicles for Volkswagen, for Audi, for Seat, for Skoda, made from 1990 to 2015.

    Main Features of VAG PRO:

    * Unique features OCLF service procedures (One-Click-Function);

    * inexpensive flasher for VAG;

    * inexpensive flasher with support UDS controllers;

    * ESP MK60EC1 decision coding blocks;

    * a tool for a complete diagnosis MQB platform (for Golf VII, for Octavia III) Support to 01.2013;

    * ZDC-loading containers in the electronic components;

    * Unlock video in motion (VIM) on the MQB platform (Discover Pro and MMI-MQB);

    * Coding controllers for PR-codes;

    * "Login finder" - allows you to scan and logins in the CAN controllers UDS;

    * Support for the new for Polo in 2014 Facelift;

    * Support for the new for Passat B8;

    * Full support for Audi TT-3 on the platform of the IBC;

    * Full support for Skoda Fabia III

    New in Version 5.5.1:

    Support for new addresses entered in the MLB-Evo platform

    Update database-ODX (support for all models 2015)

    Major Changes in the PR encoder:

    * Now it is possible to keep PR-codes of a file

    * PR-self-sustaining encoder may select codes known PR-analysis of current data stored in the ECU

    * You can compare the data stored in the ECU against the calculated data, choose what you want to download.

    * OCF "Activating automatic folding mirrors", the problem is illuminated space around the machine solved - Thanks Ciamardo / vcp-forum.de

    * The new team in the Scripter: GetCardSerial, returns the current smart card number. You can use it to prepare a script that will run only on these smartcards.

    * Enhanced TXT-coding, coding calculation is now faster APDUs.

    * Updated data base DTC- Fixed problems with parameterization 7N0 cameras

    * Fixed problems with parameterization 5M0 ...... F AFS modules

    * OCF new section called "Apps", which is: Download the parameter data, coding for PR-code, BCM, and so forth programmer..

    * The new procedure OCF "FlashFile Dumper" - can extract content from Flash files (*

    .SGO, * .FRF, * .ODX) in a binary dump. Note: The source data format is not changed, *

    so that if a Flash file kriptovat and compressed, the binary file will be the same.

    * Fixed an issue in the Gateway Sheet MLB-EVO (B7 II, A4 B9) - not all ECU were available through the Gateway.

    * Updated database of error codes (added more than 200 new codes, including the MQB / MLB-EVO platform)

    * New Firmware v.1.1 for interfaces (04.0D / 02.04) v.2.0 (0A.04 / 0B.04) to support new protocols (TCP-IP) used on the MLB-EVO platform

    * Fixed a connection problem with the address 46 (room unit) on the MLB-EVO (B9 A4 / Q7 4M) platform

    * Reduced time delays during the loading of large data blocks in the non-flash modes.

    This contributes to a more stable connection when connected directly to the ECU (Direct Connect), popular among fans VAG.

    Supported Cars:

    1. For Audi

    A2 2009-

    A3 8P 2003-

    A3 - platform MQB-

    A4 model 8E wariant B7 (Engine, transmission, airbags, ABS, park) 2005-

    A4 model 8K wariant B8 (UDS + TP2.0) 2008-

    A5 model 8K (UDS) 2007-

    A6 model 4F 2004-

    A8 model 4E 2003-

    Q3 (UDS) 2010-

    Q5 (UDS) 2008-

    Q7 (TP2.0 + UDS) 2006-

    S5 model 8K

    (R)S6 model 4F

    R8 (UDS)

    TT model 8J 2007-

    2. For Mercedes

    For Sprinter (VW Crafter) - - Only the engine and immobilizer

    3. For Seat

    For Altea

    For Leon MQB 2013-

    For Leon model 1P 2005-

    For Toledo model 5P 2004-

    For Exeo 2008- (Engine, transmission, airbags, ABS, park)

    4. For Skoda

    octavia model 1Z 2004 -

    octavia platform MQB -

    superb II B6 2008-

    fabia model 5J 2007-

    yeti 2009-

    5. For Volkswagen

    For Crafter (immobilizer, engine)

    For Caddy model 2K 2005-

    For Eos

    For Golf V model 1K

    For Golf VI model 5K

    For Golf VII platform MQB

    For Golf Plus

    For Jetta II model 1K

    Transporter / Multivan (Only after the CAN-BUS drive for storing data)

    Multivan/Transporter GP model 7E (UDS) 2009-

    For Passat B6 model 3C 2005-

    For Passat CC-

    For Phaeton GP 2007-

    For Polo model 6R 2009-

    For Polo FL MQB 2014-

    For Scirocco III-

    For Touran-

    For Tiguan-

    For Touareg GP 2007-

    For Touareg NF 2010

    6. K-line ( KWP1281, TP/KWP2000)

    For VW Golf III, IV

    For VW Passat 3B

    For VW Bora

    For VW Transporter T5

    For VW New Beetle

    For VW Polo II,III,IV

    For Skoda Octavia I

    For Skoda Fabia i i II

    For Seat Leon I

    For Seat Toledo II

    For Seat Alhambra

    For Seat Ibiza II, III, IV

    For Audi A2,A3,A4,A6 K-Line

    Notes for Audi A4:

    1. Option A4 8E B6 model

    This model has a can-bus (TP1.6), but it is not connected to the diagnostic socket. The car is fully diagnosed on the K-line (VCP required interface + K). Used protocols KWP2000 and KWP1281 it.

    2 .Model A4 8E, B7 option

    This model has a CAN BUS TP2.0, but the diagnostic socket is only connected to the so- called CAN-Antrieb, i.e. Engine, transmission, airbags, ABS, Quattro drive.

    In addition, a standard K-line. In other words, VCP fully supports the diagnosis B7 models, but only in the CAN-Antrieb. Other controllers are available through the K-Line and KWP2000 KWP1281 protocols.

    Package list:

    1pc x VAG PRO

    1pc x CD
