FVDI2 ABRITES Commander For BMW And MINI V10.4+Hyundai V2.1 + Kia V2.1+Tag V6.2
FVDI2 ABRITES Commander For BMW And MINI (V10.4)
Top 5 Reasons To Get FVDI II BMW:
1. Software Version: V10.4
2. Language: English
3. Besides The Free Software In The Specification, Now Can Also Get Free DAF or Bikes Software (Choose Either One)-Time Limited Promotion
4. Update: Before update, you need advise the FVDI ID first, we will check if the ID is in the update list which can be update by email, if not in the list, can not do it yourself. you need send back the multiplexer to us for updating. and you need pay for the shipping cost of it
5. Free Gift: Honda HDS V3.102,JLR SDD V150.00,TIS V12.00.124,VCM IDS ,OBD Terminator VAG +Kia+Tag+HyundaiBMW FVDI2 Description
FVDI Connection Picture:
Notice:
1. English Language Only
2. Update: If you want to update your FVDI ABRITES Commander to 2016 FVDI2, need to ship back complete package, and it will cost usd280. If the old usb dongle not in the package, it will cost total usd330 then.
When obtaining authorization, operate by following the next steps:
Step 1. Connect the Softdog to FVDI2. Do not connect Softdog to the computer, otherwise the Softdog green light or red light will on, and result in authorization fail.
Step 2. Use USB cable to connect FVDI2 and the computer, but do not connect FVDI2 to the car. Wait until FVDI2 green light on and Softdog red light on, you succeed getting authorization. If FVDI2 red light on or Softdog green light on, repeat the above steps.
After get authorization for FVDI2, follow the next steps to connect.
Step 1. Connect the Softdog to FVDI2 (Note: do not connect Softdog to the computer).
Step 2. Use USB cable to connect FVDI2 and the computer. Wait until FVDI2 green light on and Softdog red light on, connect Softdog USB cable to the computer. During the procedure, the Softdog red light keeps on (Note: do not connect FVDI2 to the car)
Step 3. Till the above 2 steps work well, connect FVDI2 to the car.
ABRITES Commander for BMW is a PC - Windows based diagnostic software for dealer level access to the vehicle (identification, trouble codes and so...), mileage recalibration, key programming, programming vehicle order. Tool can access CAS1, CAS2, CAS3 and CAS3+ by OBDII independent from the firmware of the CAS. Also you can perform unusual for remaining diagnostic tools operations with the electronic modules inside of the vehicle like programming Vehicle Order and Coding of electronic control units. Access to the EEPROM memory of the units in the vehicle.
BMW FVDI2 Covers Vehicles
BMW series starting from E36 up to latest models F series (F01,F10,F20,F25 and so...).BMW FVDI2 Functions Included in The Base Package (FVDI2 Interface)1. Identification (VIN, mileage, production data)2. Read and clear diagnostic trouble codes (current, history and shadow)3. Added DTCs in 17 DTC conditions information (Odometer value, Timestamp, full engine status report for EDC17)4. Some DTCs (mostly that of F series) are given detailed documentation of what caused the problem and how the problem should be handled5. Manager of service intervals, reset service reminders (CBS)6. Measured values/live data7. Read and Program Engine Control Unit flash memory for tuning purposes by OBDII8. Entering and leaving from logistic mode of the modules in the vehicle9. Synchronization DME/DDE and EWS/CAS, CAS and ELV10. Enable / Disable of the keys11. Enable / Disable of TV function for E3x,E46,E5x,E83,E85,E86 (for the next bodies available via unit coding)12. Ability for diagnostic on internal CAN buses13. Read / Program mileage from the IKE, LCM, EWS, ECU, ABS, VTG, EGS (please refer coverage list)14. Displaying KEY CUTTING code (mechanical code) stored in CAS modulesBMW FVDI2 Special Functions:1. Service intervals/CBS - ability for programming of service counters by OBDII2. Programming flash memory of all electronic control units by OBDII (can be used directly databases released from BMW)3. Programming Vehicle Order data (you can add new units to configuration of the vehicle) - E body4. Coding (configuration) of each electronic control unit in the vehicle - E body5. Programming identification of the modules in the vehicle6. Programming User Information Fields in the electronic modules7. Read / Write of memory of the electronic control modules8. Program mileage stored in CAS1, CAS2 and CAS3 by OBDII9. Program keys by OBDII - CAS1, CAS2 and CAS3 systems - support latest versions CAS3 updated in 2011 year10. Key programming for CAS3+ with latest firmware version (ISTA-P 45)11. Preparing a keys by dump for BMW models with CAS4 - newest BMW 1, 5, 5 GT, 6, 7, X3 series ( body Fxx)12. Read / Write eeprom from CAS1 via OBDII13. Read / Write eeprom data from CAS2/CAS3 via dash connector or cas-connector14. Read / Program mileage stored in different electronic control units by OBDII like ECU, EGS, SGM, JBBF and many others15. Extracting and programming synchronization code between ECU and CAS by OBDII16. Ability to works together with transponder programmerNot Granted for All Type of Control Modules.
![]()
Package including:
1pc x FVDI BMW Interface1pc x Tag Key Tool
1pc x Dongle
1pc x OBDII Cable
1pc x Connect Cable
1pc x USB Cable
1pc x CD
1pc x Carrying Case
FAQ:
Q1: FVDI BWM supports BMW CAS4 for not?
A1: Yes it can do BMW CAS4
Q2: When I update the FVDI BWM,it shows "error4" ,and the indicate light turns from green to red on the multiplexer
A2: It means you failed the update,just do it again.
Q3: Is there CAS Connector in the package?
A3: Yes there is.
